IR remote receivers can be enabled or disabled. The default is enabled. IR receivers are positioned on
the front and back of the projector (see section 8.1 of this User Guide for further information).
OSD transparency can be enabled or disabled. The default is enabled. The menu background is black
when not transparent.
OSD placement changes the displayed menu position on screen. Options are left, center and right. The
default is left.
DP edid provides EDID management for the specified video input. Options for DP are WQXGA@60,
WQXGA@120, WUXGA@60, WUXGA@120. The default option is WQXGA@60 for native WQXGA
resolution projectors and WUXGA for WUXGA native resolution projectors.
DVI-1 edid provides EDID management for the specified video input. Options for DVI-1 are WQXGA@60,
2560x800@120, 2560x800@60, WUXGA@60. The default option is WQXGA@60 for native WQXGA
resolution projectors and WUXGA for WUXGA native resolution projectors.
DVI-2 edid provides EDID management for the specified video input. Options for DVI-2 are WQXGA@60,
2560x800’120, 2560x800@60, WUXGA@60. The default option is WQXGA@60 for native WQXGA
resolution projectors and WUXGA for WUXGA native resolution projectors.
8.10.4 Status Menu
The status menu provides source info, product serial number, part number and firmware revision.
NOTE! Additional source FPGA, display FPGA, LED FPGA and TI revision firmware details are also
displayed.
Source info displays video timing information for the selected projector input (data refreshes when
menu function is selected, data does not update in real-time).
Source info sub menu features include:
Horizontal resolution: 2560
Vertical resolution: 1600
Horizontal total: 2720
Vertical total: 1646
Pixel clock (MHz): 268.500
Horizontal freq (kHz): 98.713
Vertical frequency: 59.970
