IP address displays the address issued when HCP is enabled. When DHCP is disabled settings can
be configured using the numeric keys on the remote control or keypad.
Subnet mask determines which subnet an IP address belongs to. Settings can be configured
using the numeric keys on the remote control or keypad.
Default gw (gateway) denotes the route to your subnet from another subnet. Settings can be
configured using the numeric keys on the remote control or keypad.
HW addr (MAC address) is a unique identifier for each unit and cannot be changed.
Image orientation selects between desktop front (upright) / desktop rear (mirrored) / ceiling front
(upside down) and ceiling rear (mirrored). Mirrored is used for rear-projection, upside-down for ceiling-
mount.
Indicators enables and disables the backlight of the Keypad LCD. The default setting is enabled.
RGB LED power adjusts the luminous intensity / output of the red, green and blue LED diodes. The
adjustment range is 7 to 100%. The default setting is 100%.
Diagnostics
Diagnostics sub menu features include:
Temperature control indicates cooling fan speeds (RPM) and internal temperature sensor values
(in degrees Celsius).
Statistics displays run times for fans and illumination sources.
Error code(s) are automatically generated when a fault occurs. Generated codes should be
reported back to the manufacture or an appointed dealer.
Test pattern displays embedded internal test pattern images. Patterns are toggled using the keypad
arrow keys. Supported test pattern images are none, black, white, red, green, blue, white, magenta,
cyan, yellow. The default is none.
Lens motors can be enabled or disabled. The default is enabled. Effected motors are lens shift, zoom,
focus and iris
Service requires a unique password for access. Service should only be used by authorised personnel.
OSD status can be enabled or disabled. If enabled, messages will appear in the OSD field. If disabled,
messages will not appear in the OSD field.
Projector ID is used in conjunction with the projector remote control which can be used in broadcast or
individual mode of operation. Projector ID allows setting of a user definable number from 0 (zero) to
999. This number is displayed in the OSD field (if enabled). You can show the projector ID by pushing the
ID button on the remote control or via an ASCII command.
