VX600 All-in-One Controller User Manual
www.novastar.tech
4
− When the device is connected with a fiber converter, the port is used as
an output connector.
− When the device is connected with a video processor, the port is used as
an input connector.
− Max. capacity: 1x 4K×1K@60Hz or 2x 2K×1K@60Hz video inputs

OPT 2: For output only, with copy and backup modes
OPT 2 copies or backs up the output on 6 Ethernet ports.
Control Connectors
Connector
Qty
Description
ETHERNET
1
Connect to the control PC or router.
USB
2

USB 2.0 (Type-B):
− Connect to the control PC.
− Input connector for device cascading

USB 2.0 (Type-A): Output connector for device cascading
GENLOCK IN-
LOOP
1
Connect to an external sync signal.

IN: Accept the sync signal.

LOOP: Loop the sync signal.
Note:
Only the main layer can use the mosaic source. When the main layer uses the mosaic source, PIP 1 and PIP
2 cannot be opened.
