ULTIMATE XL-K
ULTIMATE XL-D
Control Unit
Motor Handpiece
Turbine Adapter (option)
Air Turbine (option)
Knee Controller (Ultimate XL-K)
Pedal
Speed Control Knob
Turbine / Motor Selector Switch
Forward / Reverse Selector Switch
Auto Cruise Switch
Indicator
Power Switch
Motor Connector
Turbine Adapter Connector
Fuse Box
Handpiece Stand
Foot Pedal Connector (Ultimate XL-D)
1. Component Names
1
7
8
9
10
11
7
8
9
10
11
2
3
5
12
12
4
4
3
6
2
1
13
14
15
16
16
13
14
15
17
English
