Display System Utilization
en-938821/2 4 - 39
4
4.10 Display of Inputs/Outputs
Certain input/output information on the machine processor can be used by the CNC and displayed on specific pages.
Requirements
Basic softkeys displayed.
Actions
Select the "CNC COMMUNICATION DISPLAY" menu. ☞
PLC
I / O
Display of the "CNC COMMUNICATION DISPLAY":
CNC COMMUNICATION DISPLAY
> 0 PLC OPERATOR MESSAGES
1 EXTERNAL PARAMETERS
2 PLC MEMORY
3 PLC USER SCREEN
4 QVN INFORMATION
5 LADDER ANIMATION
10 DNC1 - WIRE-TAP
?❙
To select an item, move the cursor onto the item or enter the item number then press .
Exit from the procedure
Select a display page.
