NUM 1050 M - Display of Programme-Being Executed

Display System Utilization
en-938821/2 4 - 35
4
4.8 Display of Programme-Being Executed
Requirements
Basic softkeys displayed.
Actions
Select the programme page. ☞
PROG.
Display of the programme area being executed with the current block the current block highlighted:
AUTO
MODE
START CYCLE
N40 G00 G41 X0 Y-20
N50 Z-5 F2000
N60 G01 Y80 EB20
N70 G02 X0 Y118 R19
N80 G01 X121 EB13 EF50
