NUM 1050 M - Page 129

CNC Operation
en-938821/2 5 - 7
5
5.1.1.4 Continuous Jog
Requirements
JOG softkeys selected (See 5.1.1.1).
Actions
Select the continuous jog function. ☞
FREE
Display of the "CONT." indicator in the status window (See 3.1.3).
Select the manual mode (See 5.1.1.2).
Control the jog by continually pressing the axis controls of the machine panel.
Jog along the axis in the demanded direction while it is being pressed.
Notes
The "FEED STOP" button is ineffective during continuous jog.
5.1.1.5 Handwheel Jog
Requirements
JOG softkeys selected (See 5.1.1.1).
Actions
Select the handwheel jog function. ☞
HANDWH
Display of the "HANDWH" indicator in the status window (See 3.1.3).
Select the manual mode (See 5.1.1.2).
Use the corresponding controls to jog the axes.
Jog along the axis linked to the handwheel:
- value proportional to the handwheel rotation,
- direction corresponding to the handwheel rotation.
