CNC Operation
en-938821/2 5 - 13
5
Example:
The following values:
- Y DAT1 displayed = - 307.783
- Op/spindle datum shift = + 5 (test bar dia. 10),
give:
Real Y DAT1 = - 302.783
Enter Y -302.783. ☞
The real YDAT1: -302.783.
5.2.1.3 Input of Part Origin Shifts via the Keyboard
When the part origin shifts or center of turntable shifts (DAT1) are known, they can be directly entered into the system
via the keyboard.
Requirements
No mode being executed. If a mode is being executed, selection of this mode is only taken into account after an
interruptible block.
Actions
Select the origin shift mode (See 5.2.1.1).
For each axis, enter "[axis name] [value of DAT1]". ☞
Transfer of the entered shifts to the DAT1 values which are then displayed on the screen.
5.2.1.4 Input of Programme Origin Shifts
Programme origin shifts (DAT2) are entered via the keyboard (this is not required for systems fitted with an index table).
Requirements
No mode being executed. If a mode is being executed, selection of this mode is only taken into account after an
interruptible block.
Actions
Select the origin shift mode (See 5.2.1.1).
Display the dialogue line for DAT2 input. ☞
SHIFTS
Display of dialogue line for "DAT2: ❚".
For each axis, enter "[axis name] [value of DAT2]". ☞
Transfer of the entered shifts to the DAT2 values which are then displayed on the screen.
