CNC Operation
en-938821/2 5 - 37
5
Deletion of a block
System in edit mode and block preceding the block to be deleted (new block N50) selected.
Original blocks Modified blocks
N50 G41 X18 Y-10 N50 G41 X18 Y-10
N50 Z-3
Select the next block (N50). ☞
➞
Delete the old block N50. ☞
_
-
Deletion of the block and selection of next block.
Replacement of one block by another
System in edit mode and block to be replaced (block N60) selected.
Orignal block New block
N60 G01 Y50 F100 M08 N60 G01 Y0
Enter "#N60 G01 Y0". ☞
Replacement of block N60 by "N60 G01 Y0".
Deletion of a string in a block
System in edit mode and block to be modified (block N80) selected.
Original block Modified block
N80 G01 G40 Y70 N80 G01 Y70
Enter "#;G40 ;". ☞
Replacement of string "G40" of block N80 by an empty string.
Insertion of a part of a programme
System in edit mode and block preceding the blocks to be inserted (block N120) selected.
Blocks to be inserted Modified part of programme
%204
... ...
N220... N120 X70
$ CUTTING OF GROOVE WITH RADIUS $ CUTTING OF GROOVE WITH RADIUS
N230 G00 Y20 N230 G00 Y20
N240 G01 X50 N240 G01 X50
N250 G03 X40 Y10 R10 N250 G03 X40 Y10 R10
N260 G01 Y-10 N260 G01 Y-10
... ...
Enter "I %204 N220+1 N260". ☞
Insertion of that part of programme %204 between blocks N220 + 1 and N260 after block N120, selection of block
"CUTTING OF GROOVE WITH RADIUS".
