en-938821/2 8 - 5
8
Operator-Accessible Maintenance
!
CAUTION
The battery must be replaced within 15 minutes at most so as not to lose the data present
in the RAM. A capacitor takes over for the battery to supply the SRAM memory modules
during replacement.
8.1.1.2 Adding an SRAM Memory Module
Tilt the module into the connector with the fool-proofing notch on the left (1).
2
1
Notch
Push the module down into a horizontal position until it snaps into place (2).
