8 - 46 en-938821/2
8.8.7.3 Verification of Backed Up Programmes
Verification of a backed up programme may be performed immediately after unloading or at any time to verify the
conformity of the backup programmes with those in the protected area.
Requirements
CNC connected to the peripheral (See C.2).
Peripheral ready to transmit binary data (See peripheral manual).
CNC reception baud rate (See 8.3) conforming to the peripheral reception baud rate.
Programmes present in the protected area.
The "VERIFY PROTECTED ZONE" page is displayed with the question "VERIFY? (Y,N)" after acceptance or refusal
of unloading (See 8.8.7.1 and 8.8.7.2).
Actions
Confirm verification. ☞
Y
Start data transmission via the peripheral.
Display of three lines identifying the type of backup verified, e.g.:
Single programme (COPY) All programmes (COPY) All programmes (backup)
VERSION: 00 VERSION: 00 VERSION: 00
IDENTIFICATOR: INC1 IDENTIFICATOR: GLO1 IDENTIFICATOR: ZON1
PROG. No .: %1.2 AFFAIRE No.: * AFFAIRE No.: XXXXXX00
and of the message:
VERIFICATION IN PROGRESS
At the end of the verification, display of message:
BACKUP OK!
Return to the "RESIDENT MACROS" menu. ☞
EXIT
Incidents
The backed up data differ from those in the protected area
Display of the message:
INCORRECT BACKUP
Return to the "RESIDENT MACROS" menu. ☞
EXIT
