A.1.3 Additional Function Summary Table
ED: Programmed angular shift
Syntax: N.. ED..
Cancellation: ED0 or different ED...
EG: Programmed acceleration modulation
Syntax: N.. EG..
Cancellation: Different EG....
EM+/-: Outside dimensions of the part in 3D graphic display
Syntax: N.. EM+ X.. Y.. Z.. EM- X.. Y.. Z..
F: Feed rate, dwell, number of thread starts
Syntax:
N.. G93 F.. (feed rate in V/L).
N.. G94 F.. (feed rate in mm/min degrees/min or inch/min)
N.. G95 F.. (feed rate in mm/rev or inch/rev)
N.. G04 F.. (dwell in seconds)
N.. G31 F.. (number of thread starts)
Cancellation: different F.. in G93, G94 and G95; end of block in G04 and G31
S: Spindle RPM, number of subroutine repeats
Syntax:
N.. G97 S.. (spindle speed in RPM, see Sec. 4.3.2)
N.. G77 [H..] [N.. N..] S.. (subroutine call and repeats)
Cancellation: S0 or different S..
T: Tool number
Syntax: N.. T.. M06 (tool change)
Cancellation: T0 or different T..
D: Correction number
Syntax: N.. D.. (call of correction)
Cancellation: D0 or different D..
