NUM 1050 M - Page 6

4 en-938821/2
6 Operational Problems 6 - 1
6.1 Indicator "FDHLD" Displayed 6 - 5
6.2 No Movement in Manual Mode 6 - 6
6.3 No Movement in Automatic Mode 6 - 8
6.4 No Cycle Start 6 - 11
6.5 No Block Sequencing 6 - 12
6.6 Faults Detected by the System 6 - 17
6.7 Data Modification 6 - 17
6.8 Failure on Analogue Input/Output Cards 6 - 17
6.9 Power Failures 6 - 18
7 System Faults 7 - 1
7.1 Hardware Fault 7 - 5
7.2 Customisation Error 7 - 5
7.3 Temporary Customisation 7 - 6
7.4 Customisation Overrun 7 - 6
7.5 Sampling Period Too Small 7 - 7
7.6 Parameter Table Not Conforming to
Software Version 7 - 8
7.7 A Declared Axis Missing 7 - 9
7.8 Not Enough Memory to Execute the Pocket
Module 7 - 10
7.9 Wrong Number of PLC Axes 7 - 10
7.10 Incorrect Sampling Period with UC SII CPU 7 - 11
7.11 Sensor Declared Connected Several Times
to the QVN Card 7 - 11
7.12 Incoherent QVN Sensor Address 7 - 12
7.13 Sensor Declared on QVN Card but
Detected on an Axis Card 7 - 12
7.14 Undeclared Speed Sensor Connected to
the QVN Card 7 - 13
7.15 Speed Sensor Declared Several Times 7 - 13
7.16 Speed and Position Sensor Declared on
Several Axes 7 - 14
7.17 Position Sensor Not Found on Axis Card
and Not Declared as QVN Sensor 7 - 14
7.18 Several Axis Drive Sensors Have the Same
Address 7 - 15
7.19 List of Drives Different from the List of
QVN Axes 7 - 15
7.20 QVN Axes Missing 7 - 16
7.21 Missing QVN Measured-Only Axes 7 - 16
7.22 Sampling Period Not Within the Authorised
Values 7 - 17
7.23 Editing Parameter P98 7 - 17
