Display System Utilization
en-938821/2 4 - 17
4
Incidents
A variety of incidents may occur, indicated by one of the following messages:
Message Cause Action
Programme number not The specified Acknowledge the message
found programme does not ☞
Any
character
exist in the memory Select another programme
Block number not found One of the selected Acknowledge the message
blocks does not exist ☞
Any
character
Select another block
Scaling not possible, No movement on one Acknowledge the message
one axis is not of the plane axes ☞
Any
character
programmed Select another plane or correct the programme
(See 5.4.2.2)
error xxx block Nyyy Programming error Exit the display
Error text ☞
EXIT
Correct the programme (See 5.4.2.2)
4.6.1.3 Scaling of Display Planes
Requirements
Graphic display parameters page displayed.
Programme to be displayed selected (See 4.6.1.1).
Actions
Select the scaling function for both planes of the part. ☞
SCALE
1 + 2
Scaling of both planes (similar to 4.6.1.2, but no display, therefore quicker).
The minimum and maximum dimensions of the two planes are displayed in the graphic display parameters page.
Incidents
A variety of incidents may occur, indicated by one of the following messages:
Message Cause Action
Programme number not The specified Acknowledge the message
found programme does not ☞
Any
character
exist in the memory Select another programme
Block number not found One of the selected Acknowledge the message
blocks does not ☞
Any
character
exist Select another block
