19
Ite
m
Interface Description
5 DDR5 SDRAM
On-Board
Memory
20 units of DDR5 SDRAM for a total of 32GB @ 5200 or 5600MT/s. 128bit + 16bit ECC,
solder-down memory
6 NC-SI
Management
Interface
NC-SI 20 pins BMC connectivity for remote management
7 USB 4-pin RA
Connector
Used for OS image loading
8 1GbE OOB
Management
Interface
1GbE BASE-T OOB management interface
9 MMCX RA PPS
IN/OUT
Allows PPS IN/OUT
10 External PCIe
Power Supply
Connector
An external 12V power connection through an 8-pin ATX connector
Applies to models: B3210E, B3210 and B3220
11 Cabline CA-II
Plus
Connectors
Two Cabline CA-II plus connectors are populated to allow connectivity to an additional
PCIe x16 Auxiliary card
Applies to models: B3210E, B3210 and B3220
12 Integrated
BMC
DPU BMC
13 SSD Interface 128GB
14 RTC Battery Battery holder for RTC
15 eMMC x8 NAND flash
3.3 Interfaces Detailed Description
3.3.1 DPU System-on-Chip (SoC)
NVIDIA® BlueField®-3 is a family of advanced IC solutions that integrate a coherent mesh of 64-bit
Armv8.2+ A78 Hercules cores, anNVIDIA® ConnectX®-7network adapter front-end, and a PCI
Express switch into a single chip. The powerful DPU IC architecture includes an Armv multicore
processor array, enabling customers to develop sophisticated applications and highly differentiated
feature sets. Leverages the rich Arm software ecosystem and introduces the ability to offload the
x86 software stack.
At the heart of BlueField-3, the ConnectX-7 network offload controller with RDMA and RDMA over
Converged Ethernet (RoCE) technology delivers cutting-edge performance for networking and
storage applications such as NVMe over Fabrics.Advanced features include an embedded virtual
switch with programmable access lists (ACLs), transport offloads, and stateless encaps/decaps of
NVGRE, VXLAN, and MPLS overlay protocols.

Nvidia BlueField-3 Specifications

General

Product Type	DPU (Data Processing Unit)
Power Consumption	Up to 75W
Manufacturing Process	7nm
Operating Temperature	0°C to 70°C
Virtualization	SR-IOV, Virtio
Target Applications	Cloud, Networking, Storage
Memory	Up to 16 GB DDR4
Memory Bandwidth	Up to 200 GB/s
Networking	Up to 400 GbE
PCIe	PCIe Gen4 x16
Storage Acceleration	NVMe over Fabrics (NVMe-oF)
Security	Hardware root of trust, Secure boot
Form Factor	PCIe Card
Acceleration Engines	Networking, Storage, Security
Software Support	NVIDIA DOCA
Cache	L1, L2, L3 caches
