Data Rate
InfiniBand NDR200/HDR/HDR100/EDR/FDR/SDR
Ethernet (Default Speed) 200/100/50/25/10 Gb/s
Protocol Support
InfiniBand: IBTA v1.5
(a)
Auto-Negotiation: NDR200 (2 lanes x 100Gb/s per lane) port, HDR (50Gb/s per
lane) port, HDR100 (2 lane x 50Gb/s per lane), EDR (25Gb/s per lane) port, FDR
(14.0625Gb/s per lane), 1X/2X/4X SDR (2.5Gb/s per lane).
Ethernet: 200GAUI-2 C2M, 200GAUI-4 C2M, 200GBASE-CR4, 100GAUI-2 C2M,
100GAUI-1 C2M, 100GBASE-CR4, 100GBASE-CR2, 100GBASE-CR1, 50GAUI-2 C2M,
50GAUI-1 C2M, 50GBASE-CR, 50GBASE-R2 , 40GBASE-CR4, 40GBASE-R2, 25GBASE-
R, 10GBASE-R, 10GBASE-CX4, 1000BASE-CX, CAUI-4 C2M, 25GAUI C2M, XLAUI
C2M , XLPPI, SFI
Electrical and Thermal
Specifications
Voltage: 12V
Electrical and thermal specifications are provided in "NVIDIA BlueField-3 DPUs
and SuperNICs Electrical and Thermal Specifications" document. You can access
the document either by logging into NVOnline or by contacting your NVIDIA
representative.
Environmental
Temperature Operational 0°C to 55°C
Non-operational
-40°C to 70°C
(b)
Humidity Operational 10% to 85% relative
humidity
Non-operational 10% to 90% relative
humidity
Altitude (Operational) 3050m
Regulatory
Safety CB / cTUVus / CE
EMC CE / FCC / VCCI / ICES / RCM
RoHS RoHS compliant
Regulatory Model Number D3B6
Notes:
(a)
The BlueField-3 DPU supplement the IBTA auto-negotiation specification to get better bit error
rates and longer cable reaches. This supplemental feature only initiates when connected to
another NVIDIA InfiniBand product.
(b)
The non-operational storage temperature specifications apply to the product without its
package.
8.9 DPUs Mechanical Drawing and Dimensions
OPNs Mechanical Drawings
All dimensions are in millimeters. The PCB mechanical tolerance is +/- 0.13mm.
The diagrams may differ for different cards and are provided here for illustration purposes
only.
