Nvidia BlueField-3 User Manual

61
•
•
•
•
8.4 B3210LSuperNICs Specifications
OPNs
900-9D3B4-00CC-EA0: Crypto Enabled with integrated BMC
900-9D3B4-00SC-EA0: Crypto Disabled with integrated BMC
BlueField-3 SoC
BlueField-3 E-Series-8Arm-Cores - 505MHz/2000MHz
Physical
Single-Slot FHHL Card Dimensions:111.15mm x 167.65mm
Tall Bracket Dimensions:120.5mm x 21.95mm
Heatsink Dimensions (Length, Width, Height):139.6mm x 92.7mm x 10.2mm
Interfaces
See Supported Interfaces
On-board Memory Single-channel with 10 DDR5 + ECC (64bit + 8bit
ECC)for a total of 16GB@ 5200MT/s
40GB pSLCeMMC memory + 128GB SSD
PCI Express Interface Gen 5.0 SERDES @ 32.0GT/s, 16 lanes (4.0, 3.0, 2.0
and 1.1 compatible)
Networking Connector Dual-port QSFP112 (copper and optical)
Data Rate
InfiniBand HDR100/EDR/FDR/SDR
Ethernet(Default) 100/50/25/10 Gb/s
Protocol Support
InfiniBand:IBTA v1.5
(a)
Auto-Negotiation:HDR100 (2 lane x 50Gb/s per lane), EDR (25Gb/s per lane)
port, FDR (14.0625Gb/s per lane), 1X/2X/4X SDR (2.5Gb/s per lane)
Ethernet:100GAUI-2 C2M, 100GBASE-CR4, 100GBASE-CR2, 100GBASE-CR1,
50GAUI-2 C2M, 50GAUI-1 C2M, 50GBASE-CR, 50GBASE-R2 , 40GBASE-CR4,
40GBASE-R2, 25GBASE-R, 10GBASE-R, 10GBASE-CX4, 1000BASE-CX, CAUI-4 C2M,
25GAUI C2M, XLAUI C2M , XLPPI, SFI
Electrical and Thermal
Specifications
Voltage 12V
To be updated in a future revision of this document
Environmental
Temperature Operational 0°C to 55°C
Non-operational
-40°C to 70°C
(b)
Humidity Operational 10% to 85% relative
humidity
Non-operational 10% to 90% relative
humidity
Altitude (Operational) 3050m
Regulatory
Safety CB / cTUVus / CE
EMC CE / FCC / VCCI / ICES / RCM
RoHS RoHS compliant
Regulatory Model Number D3B4
Notes:
(a)
The BlueField-3 SuperNICs supplement the IBTA auto-negotiation specification to get better bit
error rates and longer cable reaches. This supplemental feature only initiates when connected to
another NVIDIA InfiniBand product.
(b)
The non-operational storage temperature specifications apply to the product without its
package.

Nvidia BlueField-3 Specifications

General

Product Type	DPU (Data Processing Unit)
Power Consumption	Up to 75W
Manufacturing Process	7nm
Operating Temperature	0°C to 70°C
Virtualization	SR-IOV, Virtio
Target Applications	Cloud, Networking, Storage
Memory	Up to 16 GB DDR4
Memory Bandwidth	Up to 200 GB/s
Networking	Up to 400 GbE
PCIe	PCIe Gen4 x16
Storage Acceleration	NVMe over Fabrics (NVMe-oF)
Security	Hardware root of trust, Secure boot
Form Factor	PCIe Card
Acceleration Engines	Networking, Storage, Security
Software Support	NVIDIA DOCA
Cache	L1, L2, L3 caches
