Nvidia BlueField-3 - 10.2 SuperNICs Board Label Example

72
Item on Label Description Example/Additional Information
DPU BMC (Baseboard
Management Controller)
Represents the MAC address for the
1GbE OOB management port of the
DPU BMC.
Note: The base MAC address for DPU
BMC is +1 form the OOB MAC address.
S/N (Serial Number) A unique serial number that
distinguishes your DPU from others.
The S/N is used for tracking and
support purposes.
N/A
10.2 SuperNICs Board Label Example
Item on Label Description Example/Additional Information
GUID (Global Unique
Identifier)
GUIDs is a unique 16 byte identifier
of the BlueField in an InfiniBand
network, the GUID never changes.
The GUID on the label is assigned to the
System GUID of the BlueField HCA.
The System GUID represents the HCA
hardware with all its ports. Each HCA
port is assigned a dedicated Node GUID.
The Node GUID of port 0 is equal to the
System GUID.
The Node GUID of port 1 is equal to the
System GUID+1
Note: The product revisions (“Rev”) indicated on the label do not necessarily represent the
latest revisions of the cards.
