Pin# Signal Name Wire Type AWG# Detailed
Description
Pin# on the
other end
60 S_PRSNT2_L Micro coax 38 Connect to a 4.7K
pull-up resistor to
3.3V on the
motherboard side, to
detect if both the
Cabline harnesses
are connected or
not. This signal is
connected to
S_PRSNT1_L on the
BlueField DPU. In the
motherboard side,
read logic low if
both Cabline
harnesses are
connected. Read
logic 1 (3.3V) if one
or both the Cabline
harnesses are not
connected.
No wires are
connected to these
pins to ensure they
do not interfere with
the operation of
S_PRSNT1_L for the
detection when the
two Cabline
harnesses are
installed.
60
11.4 Technical Specifications
Physical
PCIe Auxiliary Card Size: 5.09 in. x 2.32 in. (129.30mm x 59.00mm)
Two Cabline CA-II Plus harnesses (white and black) Length: 15, 25 or 35cm
Power
Consumption
Voltage: 12V, 3.3V_AUX
Maximum current:100mA for the 3.3V_AUX voltage rail
PCIe
Connectivity
MTMK9100-T15 PCI Express Gen 5.0/4.0: SERDES @ 16/32 GT/s, x16 lanes
(Gen 3.0 compatible)
MTMK9100-T25 /
MTMK9100-T35
PCI Express Gen 4.0: SERDES @ 16GT/s, x16 lanes (Gen
3.0 compatible)
Environmental
Temperature Operational 0°C to 55°C
Non-
operational
-40°C to 70°C
Humidity Operational 10% to 85% relative humidity
Non-
operational
10% to 90% relative humidity
Altitude (Operational) 3050m
Regulatory
Safety: CB / cTUVus / CE

Nvidia BlueField-3 Specifications

General

Product Type	DPU (Data Processing Unit)
Power Consumption	Up to 75W
Manufacturing Process	7nm
Operating Temperature	0°C to 70°C
Virtualization	SR-IOV, Virtio
Target Applications	Cloud, Networking, Storage
Memory	Up to 16 GB DDR4
Memory Bandwidth	Up to 200 GB/s
Networking	Up to 400 GbE
PCIe	PCIe Gen4 x16
Storage Acceleration	NVMe over Fabrics (NVMe-oF)
Security	Hardware root of trust, Secure boot
Form Factor	PCIe Card
Acceleration Engines	Networking, Storage, Security
Software Support	NVIDIA DOCA
Cache	L1, L2, L3 caches
