Nvidia BlueField-3 User Manual

57
•
•
•
•
8 Specifications
8.1 B3140H SuperNICs Specifications
OPNs
900-9D3D4-00EN-HA0: Crypto Enabled with integrated BMC
900-9D3D4-00NN-HA0: Crypto Disabled with integrated BMC
BlueField-3 SoC
BlueField-3 E-Series-8Arm-Cores - 505MHz/2000MHz
Physical
Single-Slot HHHL Card Dimensions: 68.90mm x 167.65mm
Tall Bracket Dimensions:120.5 x 21.95mm
Short Bracket Dimensions:80.22mm x 22.83mm
Heatsink Dimensions (Length, Width, Height): 139.6mm x 92.7mm x 10.2mm
Interfaces
See Supported Interfaces
On-board Memory Single-channel with 10 DDR5 + ECC (64bit + 8bit
ECC)for a total of 16GB@ 5200MT/s
40GB pSLCeMMC memory + 128GB SSD
PCI Express Interface Gen 5.0 SERDES @ 32.0GT/s, 16 lanes (4.0, 3.0, 2.0
and 1.1 compatible)
Networking Connector Single-portQSFP112(copper and optical)
Data Rate
InfiniBand NDR/NDR200/HDR/HDR100/EDR/FDR/SDR
Ethernet (Default) 400/200/100/50/25/10 Gb/s
Protocol Support
InfiniBand:IBTA v1.5
(a)
Auto-Negotiation:NDR (4 lanes x 100Gb/s per lane) port, NDR200 (2 lanes x
100Gb/s per lane) port, HDR (50Gb/s per lane) port, HDR100 (2 lane x 50Gb/s
per lane), EDR (25Gb/s per lane) port, FDR (14.0625Gb/s per lane), 1X/2X/4X
SDR (2.5Gb/s per lane)
•
•
•
•
•
•
•
•
Ensure your system supports the following system hardware and power supply requirements
prior to installing your card.
Power Supply Requirement
B3140HSuperNICs:900-9D3D4-00EN-
HA0 and 900-9D3D4-00NN-HA0
B3140L SuperNICs:900-9D3B4-00EN-EA0
and 900-9D3B4-00PN-EA0
B3220L SuperNICs:900-9D3B4-00CV-EA0
and 900-9D3B4-00SV-EA0
B3210L SuperNICs:900-9D3B4-00CC-EA0
and 900-9D3B4-00SC-EA0   
A minimum of 75W system power supply through the
PCIe x16 interface
B3220DPUs: 900-9D3B6-00CV-AA0 and
900-9D3B6-00SV-AA0
B3240 DPUs: 900-9D3B6-00CN-AB0 and
900-9D3B6-00SN-AB0
B3210 DPUs:900-9D3B6-00CC-AA0
and900-9D3B6-00SC-AA0
B3210E DPUs: 900-9D3B6-00CC-EA0 and
900-9D3B6-00SC-EA0
Require a supplementary 8-pin ATX power supply
connectivity available through the external power
supply connector.

Nvidia BlueField-3 Specifications

General

Product Type	DPU (Data Processing Unit)
Power Consumption	Up to 75W
Manufacturing Process	7nm
Operating Temperature	0°C to 70°C
Virtualization	SR-IOV, Virtio
Target Applications	Cloud, Networking, Storage
Memory	Up to 16 GB DDR4
Memory Bandwidth	Up to 200 GB/s
Networking	Up to 400 GbE
PCIe	PCIe Gen4 x16
Storage Acceleration	NVMe over Fabrics (NVMe-oF)
Security	Hardware root of trust, Secure boot
Form Factor	PCIe Card
Acceleration Engines	Networking, Storage, Security
Software Support	NVIDIA DOCA
Cache	L1, L2, L3 caches
