Nvidia BlueField-3 User Manual

55
6 Setting High-Speed-Port Link Type
The following table lists the BlueField-3 supported speeds and the default networking port link type
per OPN.
Model OPN Data Transmission Rate Default Protocol and
Rate
B3140L
B3240
900-9D3B4-00EN-EA0 /
900-9D3B4-00PN-EA0
900-9D3B6-00CN-AB0 /
900-9D3B6-00SN-AB0
InfiniBand: NDR 400Gb/s
Ethernet: 400GbE
InfiniBand NDR 400Gb/s
B3140H 900-9D3D4-00EN-HA0/
900-9D3D4-00NN-HA0
InfiniBand: NDR 400Gb/s
Ethernet: 400GbE
Ethernet 400GbE
B3220
B3220L
900-9D3B6-00CV-AA0 /
900-9D3B6-00SV-AA0
900-9D3B4-00CV-EA0 /
900-9D3B4-00SV-EA0
InfiniBand: NDR200 200Gb/s
Ethernet: 200GbE
Ethernet 200GbE
B3210
B3210E
B3210L
900-9D3B6-00CC-AA0 /
900-9D3B6-00SC-AA0
900-9D3B6-00CC-EA0 /
900-9D3B6-00SC-EA0  
900-9D3B4-00CC-EA0 /
900-9D3B4-00SC-EA0
InfiniBand: HDR100 100Gb/s
Ethernet: 100GbE
Ethernet 100GbE
To configure the high-speed networking port mode, you can either use themlxconfigor
theUEFItools.
UEFI can configure the DPU device beforethe operating system is up, whilemlxconfig configures the
card once the operating system is up.According to your preference, use one of the below tools:
6.1 mlxconfig
The mlxconfig tool allows users to change device configurations without burning the firmware. The
configuration is also kept after reset. By default, mlxconfig shows the configurations that will be
loaded in the next boot. For more information and instructions, refer toUsing mlxconfig to Set IB/
ETH Parameters.
6.2 UEFI
PreBoot drivers initialize the adapter device, check the port protocol type – Ethernet or InfiniBand -
and bring up the port. Then it connects to a DHCP server to obtain its assigned IP address and
network parameters and obtain the source location of the kernel/OS to boot from. The DHCP server
instructs the PreBoot drivers to access the kernel/OS through a TFTP server, an iSCSI target, or some
other service. For more information and instructions, refer toUEFI.

Nvidia BlueField-3 Specifications

General

Product Type	DPU (Data Processing Unit)
Power Consumption	Up to 75W
Manufacturing Process	7nm
Operating Temperature	0°C to 70°C
Virtualization	SR-IOV, Virtio
Target Applications	Cloud, Networking, Storage
Memory	Up to 16 GB DDR4
Memory Bandwidth	Up to 200 GB/s
Networking	Up to 400 GbE
PCIe	PCIe Gen4 x16
Storage Acceleration	NVMe over Fabrics (NVMe-oF)
Security	Hardware root of trust, Secure boot
Form Factor	PCIe Card
Acceleration Engines	Networking, Storage, Security
Software Support	NVIDIA DOCA
Cache	L1, L2, L3 caches
