Nvidia BlueField-3 User Manual

91
Pin# Signal Name Wire Type AWG# Detailed
Description
Pin# on the
other end
55 PCIE_CX_CPU_15P Micro coax 38 Connect from the
White Cabline CA-II
Plus harness to the
PCIe x16 Rx lanes of
the CPU/GPU/End-
Point. 220nF caps
are required on this
signal on the
BlueField DPU.
55
56 PCIE_CX_CPU_15N Micro coax 38 Connect from the
White Cabline CA-II
Plus harness to the
PCIe x16 Rx lanes of
the CPU/GPU/End-
Point. 220nF caps
are required on this
signal on the
BlueField DPU.
56
57 GND GND BAR 57
58 S_PERST1_CONN_L Micro coax 38 PCIe compliant
PERST_L (active low
PCI Reset) signal for
the PCIe Cabline CA-
II Plus Connectors.
The direction of this
PERST_L signal
depends on the
implementation:
When connecting a
CPU root complex to
the PCIe Cabline CA-
II Plus interface, this
signal is driven from
the motherboard
side (from the CPU),
to the BlueField
DPU. When
connecting a GPU or
an end point to the
PCIe Cabline CA-II
Plus interface, this
signal is driven from
the BlueField DPU
side (which operates
as a PCIe switch in
this case), to the
GPU or end-point on
the motherboard
side.
58
59 No Wire 59

Nvidia BlueField-3 Specifications

General

Product Type	DPU (Data Processing Unit)
Power Consumption	Up to 75W
Manufacturing Process	7nm
Operating Temperature	0°C to 70°C
Virtualization	SR-IOV, Virtio
Target Applications	Cloud, Networking, Storage
Memory	Up to 16 GB DDR4
Memory Bandwidth	Up to 200 GB/s
Networking	Up to 400 GbE
PCIe	PCIe Gen4 x16
Storage Acceleration	NVMe over Fabrics (NVMe-oF)
Security	Hardware root of trust, Secure boot
Form Factor	PCIe Card
Acceleration Engines	Networking, Storage, Security
Software Support	NVIDIA DOCA
Cache	L1, L2, L3 caches
