Nvidia BlueField-3 User Manual

60
•
•
OPNs
900-9D3B4-00CV-EA0: Crypto Enabled with integrated BMC
900-9D3B4-00SV-EA0: Crypto Disabled with integrated BMC
On-board Memory Single-channel with 10 DDR5 + ECC (64bit + 8bit
ECC)for a total of16GB@ 5200MT/s
40GB pSLCeMMC memory + 128GB SSD
PCI Express Interface Gen 5.0 SERDES @ 32.0GT/s, 16 lanes (4.0, 3.0, 2.0
and 1.1 compatible)
Networking Connector Dual-port QSFP112 (copper and optical)
Data Rate
InfiniBand NDR200/HDR/HDR100/EDR/FDR/SDR
Ethernet(Default) 200/100/50/25/10 Gb/s
Protocol Support
InfiniBand:IBTA v1.5
(a)
Auto-Negotiation:NDR200 (2 lanes x 100Gb/s per lane) port, HDR (50Gb/s per
lane) port, HDR100 (2 lane x 50Gb/s per lane), EDR (25Gb/s per lane) port, FDR
(14.0625Gb/s per lane), 1X/2X/4X SDR (2.5Gb/s per lane)
Ethernet:200GAUI-4 C2M, 200GBASE-CR4, 100GAUI-2 C2M, 100GBASE-CR4,
100GBASE-CR2, 100GBASE-CR1, 50GAUI-2 C2M, 50GAUI-1 C2M, 50GBASE-CR,
50GBASE-R2 , 40GBASE-CR4, 40GBASE-R2, 25GBASE-R, 10GBASE-R, 10GBASE-CX4,
1000BASE-CX, CAUI-4 C2M, 25GAUI C2M, XLAUI C2M , XLPPI, SFI
Electrical and Thermal
Specifications
Voltage 12V
Electrical and thermal specifications are provided in "NVIDIA BlueField-3 DPUs
and SuperNICs Electrical and Thermal Specifications" document. You can access
the document either by logging into NVOnline or by contacting your NVIDIA
representative.
Environmental
Temperature Operational 0°C to 55°C
Non-operational
-40°C to 70°C
(b)
Humidity Operational 10% to 85% relative
humidity
Non-operational 10% to 90% relative
humidity
Altitude (Operational) 3050m
Regulatory
Safety CB / cTUVus / CE
EMC CE / FCC / VCCI / ICES / RCM
RoHS RoHS compliant
Regulatory Model Number D3B4
Notes:
(a)
The BlueField-3 SuperNICs supplement the IBTA auto-negotiation specification to get better bit
error rates and longer cable reaches. This supplemental feature only initiates when connected to
another NVIDIA InfiniBand product.
(b)
The non-operational storage temperature specifications apply to the product without its
package.

Nvidia BlueField-3 Specifications

General

Product Type	DPU (Data Processing Unit)
Power Consumption	Up to 75W
Manufacturing Process	7nm
Operating Temperature	0°C to 70°C
Virtualization	SR-IOV, Virtio
Target Applications	Cloud, Networking, Storage
Memory	Up to 16 GB DDR4
Memory Bandwidth	Up to 200 GB/s
Networking	Up to 400 GbE
PCIe	PCIe Gen4 x16
Storage Acceleration	NVMe over Fabrics (NVMe-oF)
Security	Hardware root of trust, Secure boot
Form Factor	PCIe Card
Acceleration Engines	Networking, Storage, Security
Software Support	NVIDIA DOCA
Cache	L1, L2, L3 caches
