Nvidia BlueField-3 User Manual

35
Pin# Signal Name Wire Type AWG# Pin# on other
end
25 PCIE_CPU_CX_5P Micro coax 38 25
26 PCIE_CPU_CX_5N Micro coax 38 26
27 GND GND BAR 27
28 PCIE_CPU_CX_6P Micro coax 38 28
29 PCIE_CPU_CX_6N Micro coax 38 29
30 GND GND BAR 30
31 PCIE_CPU_CX_7P Micro coax 38 31
32 PCIE_CPU_CX_7N Micro coax 38 32
33 GND GND BAR 33
34 PCIE_CPU_CX_8P Micro coax 38 34
35 PCIE_CPU_CX_8N Micro coax 38 35
36 GND GND BAR 36
37 PCIE_CPU_CX_9P Micro coax 38 37
38 PCIE_CPU_CX_9N Micro coax 38 38
39 GND GND BAR 39
40 PCIE_CPU_CX_10P Micro coax 38 40
41 PCIE_CPU_CX_10N Micro coax 38 41
42 GND GND BAR 42
43 PCIE_CPU_CX_11P Micro coax 38 43
44 PCIE_CPU_CX_11N Micro coax 38 44
45 GND GND BAR 45
46 PCIE_CPU_CX_12P Micro coax 38 46
47 PCIE_CPU_CX_12N Micro coax 38 47
48 GND GND BAR 48
49 PCIE_CPU_CX_13P Micro coax 38 49
50 PCIE_CPU_CX_13N Micro coax 38 50
51 GND GND BAR 51
52 PCIE_CPU_CX_14P Micro coax 38 52
53 PCIE_CPU_CX_14N Micro coax 38 53
54 GND GND BAR 54
55 PCIE_CPU_CX_15P Micro coax 38 55
56 PCIE_CPU_CX_15N Micro coax 38 56
57 GND GND BAR 57
58 S_PERST1_CONN_L Micro coax 38 58
59 No wire No Wire 59
60 S_PRSNT2_L Micro coax 38 60

Nvidia BlueField-3 Specifications

General

Product Type	DPU (Data Processing Unit)
Power Consumption	Up to 75W
Manufacturing Process	7nm
Operating Temperature	0°C to 70°C
Virtualization	SR-IOV, Virtio
Target Applications	Cloud, Networking, Storage
Memory	Up to 16 GB DDR4
Memory Bandwidth	Up to 200 GB/s
Networking	Up to 400 GbE
PCIe	PCIe Gen4 x16
Storage Acceleration	NVMe over Fabrics (NVMe-oF)
Security	Hardware root of trust, Secure boot
Form Factor	PCIe Card
Acceleration Engines	Networking, Storage, Security
Software Support	NVIDIA DOCA
Cache	L1, L2, L3 caches
