55
34 HSI_8P
Output BlueField Card PCIE TX to Carrier Board PCIE RX
35 HSI_8N
36 GND Ground
37 HSI_9P
Output BlueField Card PCIE TX to Carrier Board PCIE RX
38 HSI_9N
39 GND Ground
40 HSI_10P
Output BlueField Card PCIE TX to Carrier Board PCIE RX
41 HSI_10N
42 GND Ground
43 HSI_11P
Output BlueField Card PCIE TX to Carrier Board PCIE RX
44 HSI_11N
45 GND Ground
46 HSI_12P
Output BlueField Card PCIE TX to Carrier Board PCIE RX
