47 HSI_12N
48 GND Ground
49 HSI_13P
Output BlueField Card PCIE TX to Carrier Board PCIE RX
50 HSI_13N
51 GND Ground
52 HSI_14P
Output BlueField Card PCIE TX to Carrier Board PCIE RX
53 HSI_14N
54 GND Ground
55 HSI_15P
Output BlueField Card PCIE TX to Carrier Board PCIE RX
56 HSI_15N
57 GND Ground
58 PERST# Output PCIe Interface Reset#
for the PCIe interface via the card IPEX connectors For System NIC mode, its direction will turn as input.
59 RSVD NA Not Connected. Keep it floating.
