NVIDIA DGX A100 Service Manual
4. Label all network, monitor, and USB cables connected to the motherboard tray for easy identi-
cation when reconnecting.
5. Unplug all power cords, and all network, monitor, and USB cables.
6. Remove the motherboard tray.
Refer to the instructions in the section Accessing the Motherboard Tray.
7. Remove the M.2 riser card from the motherboard tray by lifting the riser assembly.
8. Identify the failed M.2 module and remove it from the riser card.
1. Determine the location of the drive to remove.
10.3. Replacing the M.2 NVMe Drive 41

Nvidia DGX A100 Specifications

General

GPU	8 x NVIDIA A100 Tensor Core GPUs
System Memory	1 TB DDR4
Storage	15 TB NVMe SSD
GPU Memory	320 GB total (40 GB per GPU)
CPU	2 x 64-Core AMD EPYC 7742
Networking	8 x 200 Gb/s InfiniBand or Ethernet
Interconnect	NVIDIA NVLink
