Nvidia Jetson Orin NX User Manual

Display
PRELIMINARY INFORMATION
NVIDIA Jetson Orin NX DG-10931-001_v0.1 | 42
Table 9-3. eDP and DP Main Link Signal Requirements Including DP_AUX
Parameter Requirement Units Notes
Specification
Max Data Rate / Min UI
HBR3
HBR2
HBR
RBR
8.1 / 123
5.4 / 185
2.7 / 370
1.62 / 617
Gbps / ps
Per data lane
Number of Loads / Topology 1 load Point-Point, Differential, Unidirectional
Termination 100 Ω On die at TX/RX
Electrical Specification
Insertion Loss
E-HBR @ 0.675GHz
PBR 0.68GHz
HBR 1.35GHz
HBR2 @ 2.7GHz
HBR3 @ 4.05GHz
<=0.7
<=0.7
<=1.2
<=4.5
<=5.5
dB
Resonance dip frequency
HBR2
HBR3
>8
>12
GHz
TDR dip >85 Ω @ Tr-200ps (10%-90%)
FEXT
@ DC
@ 2.7GHz
@ 5.4GHz
<= -40dB
<= -30dB
<= -30dB
IL/FEXT plot – up to HBR2. See Figure 9-3.
IL/FEXT plot – HBR3. See Figure 9-4.
Impedance
Trace Impedance (Diff pair) 100
90
85
Ω (±10%)
100Ω is the spec. target. 95/85Ω are
implementation options (Zdiff does not
account for trace coupling)
95Ω should be used to support DP-HDMI
co-layout as HDMI 2.0 requires 100Ω
impedance (see HDMI section for addition of
series resistor RS).
85Ω can be used if eDP/DP only and is
preferable as it provides better trace loss
characteristic performance. See Note 1.
Reference Plane
GND
Trace Length (delay), Spacing and Skew
Trace loss characteristic
HBR2 or lower (@ 2.7GHz)
HBR3 (@4GHz)
< 0.64
<=0.9
dB/in
The following max length (delay) is derived
based on this characteristic. The length
(delay) constraint must be re-defined if loss
characteristic is changed.
Max PCB Via dist. from module conn.
RBR/HBR
HBR2 and HBR3
No requirement
7.62
mm
Max trace length (delay) from module to connector
RBR/HBR
Stripline
Microstrip
HBR2
Stripline
Microstrip
HBR3
215 (1137.5)
215 (975)
184 (1260)
178 (1050)
mm (ps)
6.9ps/mm assumption for Stripline,
5.9ps/mm for Microstrip.
