Nvidia Jetson Orin NX User Manual

PRELIMINARY INFORMATION
NVIDIA Jetson Orin NX DG-10931-001_v0.1 | 72
Chapter 14. Unused Interface
Terminations
14.1 Unused Multi-Purpose Standard
CMOS Pad Interfaces
The following Jetson Orin NX pins (and groups of pins) are Orin MPIO pins that support either
special function I/Os (SFIO) and GPIO capabilities. Any unused pins or portions of pin groups
listed in Table 14-1 that are not used can be left unconnected.
Table 14-1. Unused MPIO Pins and Pin Group
Jetson Orin NX Pins and Pin Groups Jetson Orin NX Pins and Pin Groups
FORCE_RECOVERY* I2S
PCIE[1:0]_CLK/RST/CLKREQ/WAKE UART
GPIO xx I2C
DP1_HPD, HDMI_CEC SPI
CAM Control, Clock
14.2 Unused Dedicated Special Purpose
Pad Interfaces
See the Unused SFIO (Special Function I/O) interface pins section in the design checklist
attached to this design guide.

Nvidia Jetson Orin NX Specifications

General

GPU	1024-core NVIDIA Ampere architecture GPU with 32 Tensor Cores
CPU	6-core ARM Cortex-A78AE v8.2 64-bit CPU
Memory	8GB 128-bit LPDDR5
Storage	16GB eMMC 5.1
AI Performance	70 TOPS (INT8)
Camera	Up to 6 cameras
Connectivity	Gigabit Ethernet
I/O	GPIO, I2C, SPI, UART
Video Decode	32x 1080p60 | 64x 1080p30
Dimensions	69.6mm x 45mm (module)
