Chapter 11. Audio
NVIDIA Orin supports multiple PCM and I2S audio interfaces. It also includes a flexible audio
port switching architecture.
Table 11-1. Jetson Orin NX Audio Pin Descriptions
Pin #
Module Pin
Name
Orin Signal Usage/Description
Recommended
Usage
Direction Pin Type
199 I2S0_SCLK GP122 I2S Audio Port 0 Clock
Audio Device
Bidir
CMOS –
1.8V
197 I2S0_FS GP125 I2S Audio Port 0 Left/Right Clock Bidir
193 I2S0_DOUT GP123 I2S Audio Port 0 Data Out Output (note)
195 I2S0_DIN GP124 I2S Audio Port 0 Data In Input (note)
226 I2S1_SCLK GP206_DAP4_CLK I2S Audio Port 1 Clock
Audio Device (i.e.
M.2 Key E)
Bidir
224 I2S1_FS GP209_DAP4_FS I2S Audio Port 1 Left/Right Clock Bidir
220 I2S1_DOUT GP207_DAP4_DOUT I2S Audio Port 1 Data Out Output (note)
222 I2S1_DIN GP208_DAP4_DIN I2S Audio Port 1 Data In Input (note)
211 GPIO09 GP167 GPIO #9 or Audio Codec Initiator Clock Audio Device Output (note)
Notes:
1. In the Direction column, Output is from Jetson Orin NX. Input is to Jetson Orin NX. Bidir is for Bidirectional signals.
2. The direction indicated for I2S[1:0]_DOUT and _DIN are associated with their use as I2S data lines. The direction for GPIO09 is associated with its use
as Audio Initiator Clock. The pins support GPIO functionality, so support both input and output operation (bidirectional).
