NVIDIA Jetson Orin NX DG-10931-001_v0.1 | 75
Chapter 17. General Routing Guidelines
17.1 Signal Naming Convention
The following conventions are used in describing the signals for Jetson Orin NX:
 Signal names use a mnemonic to represent the function of the signal. For example, I2S
interface #0 shift clock signal is represented as
I2S0_SCK. All active-low single-ended
signals are identified by an asterisk (*) after the signal name. For example,
SYS_RESET*
indicates an active-low signal. Active-high signals do not have the (*) after the signal
names. For example,
I2S0_FS indicates an active-high signal. Differential signals are
identified as a pair with the same names that end with
_P and _N (for positive and negative,
respectively). For example,
CSI_0_D0_P and CSI_0_D0_N indicate a differential signal pair.
 The signal I/O type is represented as a code to indicate the operational characteristics of
the signal. The following table lists the I/O codes used in the signal description tables.
Table 17-1. Signal Type Codes
Code
Definition
A Analog
DIFF I/O Bidirectional Differential Input/Output
DIFF IN Differential Input
DIFF OUT Differential Output
I/O Bidirectional Input/Output
I Input
O Output
OD Open Drain Output
I/OD Bidirectional Input / Open Drain Output
P Power

Nvidia Jetson Orin NX Specifications

General

GPU	1024-core NVIDIA Ampere architecture GPU with 32 Tensor Cores
CPU	6-core ARM Cortex-A78AE v8.2 64-bit CPU
Memory	8GB 128-bit LPDDR5
Storage	16GB eMMC 5.1
AI Performance	70 TOPS (INT8)
Camera	Up to 6 cameras
Connectivity	Gigabit Ethernet
I/O	GPIO, I2C, SPI, UART
Video Decode	32x 1080p60 | 64x 1080p30
Dimensions	69.6mm x 45mm (module)

Summary

Jetson Orin NX Boot Considerations

QSPI Boot Method

Details the QSPI boot method for the module.

USB Recovery Mode for Flashing

Explains the USB recovery mode for flashing firmware.

Modular Connector Details and Installation

Module Connector Specifications

Describes the 260-pin SODIMM connector and its specifications.

Module Mounting Hardware

Details mounting requirements and hardware for the module.

Module Installation and Removal Procedures

Provides instructions for installing and removing the module.

Power Supply and Sequencing

Power Supply and Sequencing Guidelines

Explains power supply and sequencing for the module.

USB and PCIe Interfaces

7.1 USB

Overview of USB 2.0 and 3.2 ports.

7.2 PCIe

Overview of PCIe interfaces.

Gigabit Ethernet Interface

Display Interfaces: eDP, DP, and HDMI

9.1 eDP and DP

Details eDP and DP connection examples.

9.2 HDMI

Details HDMI connection example and requirements.

MIPI CSI Video Input

10.1 CSI Design Guidelines

Design guidelines for MIPI CSI interface implementation.

Audio Interfaces

Miscellaneous Interfaces

12.1 I2C

12.2 SPI

12.3 UART

12.4 CAN

General Routing Guidelines

17.4 Routing Guidelines

17.5 Common High-Speed Interface Requirements

USB SS and Wireless Coexistence

18.1 Mitigation Techniques
