Oki B4545 MFP User Manual

14
Installation
Description
1 Adjustable
Paper Guide
2 Scroll Scanner
(ADF)
3Console
4Printer
5 Second Paper
Tray (Optional)
[500 pages]
6 Printer Paper
Feed Tray
7Manual Paper
Feed Tray
8Printer Output
Stacker
9USB Port
10 Chip Card
Reader
11 Access handle,
Flatbed Scanner
12 Original
document
output stacker
13 Document Feed
Tray for
scanning
1B Parallel PC port
2B USB Port
3B LAN cable
socket
4B Telephone cable
socket
5B Toner Cartridge
6B Image Drum
Cartridge
7B Telephone Cord
8B Power Cord
9B Power Socket
10B On/Off Button
1
2
3
4
5
6
7
8
9
10
11
12
13
1B
2B
3B
4B
5B
6B
7B
10B
8B
9B

Oki B4545 MFP Specifications

Printer

print speed	21 ppm
time to first page	13 seconds
print resolution	600 x 600 dpi
processor speed	92 MHz
duty cycle	12, 500 prints/copies per month

Fax

fax modem speed	33.6 Kbps
transmission speed	2.5 seconds
fax memory	500 pages (8 MB)

System Memory

standard imaging RAM	64 MB

Scanner

scan type	Color and Black & White
scan speed	1.8 sec./pg. Black & White; 16 sec./pg. Color
scan resolution	600 x 2400 dpi

Environmental

dimensions	17.9" x 17.5" x 20.5"
weight	32.0 lb. (14.5 kg)
power consumption	Operating 580W, Idle 20W, Power Save 15W
