Oki B6200 Series Setup Guide

INSTALLATION AND RELOCATION PROCEDURE > 31
4. Connect the cable of the hard disk to the connector on the printer
as shown in the diagram.
5. Hold the hard disk as shown in the diagram, and install it in the
printer. Align the arrow on the hard disk with the arrow on the
printer, and insert the bracket at the top of the disk into the install
position.
6. Tighten the screws on both sides of the hard disk.
7. Refer to “Closing the printer” on page 27.
CAUTION!
When connecting the cable, hold the disk firmly by hand to prevent it from
dropping.

Oki B6200 Series Specifications

General

Resolution	1200 x 1200 dpi
Processor	200 MHz
Connectivity	USB 2.0, Parallel
Memory	32 MB (expandable to 288 MB)
Operating Systems Supported	Windows
Print Technology	LED
