30 > INSTALLATION AND RELOCATION PROCEDURE
INSTALLING A HARD DISK
You can install a hard disk option on this printer.
1. Refer to “Preparing the printer” on page 26.
2. Remove the screws on the right and left sides of the Compact
Flash bracket (1) and remove the Compact Flash disk drive as
shown in the diagram (2).
3. Remove the cable of the Compact Flash bracket from the
connector on the printer.
NOTE
> When the Compact Flash disk (option) is installed on your printer, you
cannot install the hard disk. You can install only one of them.
> Installing this option may initialize the settings of [Network/Port] and
Allocate Memory].
CAUTION!
The hard disk is a delicate item and must be handled with care. In the event
that damage does occur, it may erase important data saved on the disk. It is
recommended that you back up your data regularly.
To Next Page
