Maintenance > 124
2. Press the cover release (a) and open the top cover (b) fully.
3. Note the positions of the four cartridges. It is essential that they go back in the same
order.
4. Pull the coloured toner release lever (1) on the cartridge to be replaced fully towards
the front of the MFP.
WARNING!
If the MFP has been powered on, the fuser may be hot. This area is
clearly labelled. Do not touch.
1. Cyan cartridge 3. Yellow cartridge
2. Magenta cartridge 4. Black cartridge
b
a
