Appendix A - Moving and transporting > 181
4. Press the cover release (a) and open the top cover (b) fully.
5. Lift each of the image drum units out of the MFP and place them on a flat table.
6. Tape each junction of the image drum and toner cartridges with vinyl tape (1).
7. Re-install the image drum units back into the MFP.
8. Close the top cover and press down firmly so that the cover latches closed.
WARNING!
If the MFP has been powered on, the fuser will be hot. This area is
clearly labelled. Do not touch.
CAUTION!
The green image drum surface at the base of each cartridge is very
delicate and light sensitive. Do not touch it and do not expose it to
normal room light for more than 5 minutes. Never expose the drum
to direct sunlight or very bright room lighting.
b
a
