Chapter 10: IBM - Standard Functions
10-21
Function Dec. Hex. ASCII
Select Cut Sheet Feeder 27 91 70 1B 5B 46 ESC [ F
3 0 03 00 ETX NUL
m
1
m
2
m
3
m
1
m
2
m
3
m
1
m
2
m
3
The parameter m
1
defines the paper feed: m
1
= 1 means manual pa-
per feed. With m
1
= 3 the current bin is selected again. The parame-
ter m
2
is reserved and must be at 0 or 1. The parameter m
3
selects a
bin when a Cut Sheet Feeder with two bins is installed: m
3
= 1 se-
lects bin 1, with m
3
= 2 the next sheet is taken from bin 2.
Character sets
Function Dec. Hex. ASCII
IBM character set I 27 55 1B 37 ESC 7
IBM character set II 27 54 1B 36 ESC 6
The IBM character sets are constructed as 8-bit character sets, i.e. a
character is assigned to each bit combination of a byte, with control
commands being assigned to some values in the range from 0 to 31.
The standard ASCII characters are assigned to the range from deci-
mal 32 to 127. In IBM character set I, the range from decimal 128 to
159 is identical with that from decimal 0 to 31, while in IBM charac-
ter set II special characters are to be found in this range. The range
from decimal 160 to 255 is identical for IBM character sets I and II
and contains the IBM graphic symbols and other special characters.
In the two following representations the non-printable ranges are
marked grey. If there are printable characters in these ranges, you
can print these out with the command All character set.
IBM character sets
