Appendix E: Paper formats and print areas
E-1
g
f
d
d
h
c
b
e
a
Format
a = 76,2 to 431,8 mm
b = 76,2 to 254 mm /
76,2 to 406,4 mm
c = printable width
d = 16,9 mm
e = 12,7 mm
f = 6,35 mm
g = 6,35 to 22,2 mm
h = 12,7 mm
print area
Appendix E: Paper formats and
print areas
Continuous Paper
Continuous paper must be punched and folded to sheet length (a).
You can use up to four layers of paper (including the original when
using duplicating paper).
● The width (b) must be between 76.2 and 254 mm for small print-
ers and between 76.2 and 406.4 mm for large printers.
● You can use paper lengths between 76.2 and 431.8 mm.
● Do not print within 8.9 mm (corresponding to four lines at six
lpi) before and after a perforation in order to avoid printing on
the perforation.
● For (g) you can select a distance of 6.35 to 22.2 mm to the trans-
portation holes by moving the spiked cylinders. Paper with
binding holes must not be printed on the left of these holes.
