Chapter 1: Assembling and setting up
1-8
Removing the paper
separator
Platen axle Catches
Fitting the paper
separator
Caution!
The print head may be hot and can burn your hands.
Wait until the print head has cooled down.
Remove the paper separator
by holding it on both sides
and pulling it gently to-
wards the front of the print-
er. Finally, fully remove the
separator.
1. When you wish to refit
the separator, fit the
catches on both sides of
the separator onto the
platen axle.
2. Now press the separator
downwards until the you
hear the catches snap into
place on both sides.
