Chapter 7: Accessories
7-28
Installation
Technical details on these
interfaces such as pin
assignment, configuration by
means of the printer menu and
interface diagnostics are to be
found in »Appendix D:
Interface data«.
Interface cards
In addition to the built-in parallel interface, three other different
serial interface cards are available:
• RS-232C
• RS-232C/Current Loop
• RS-422A
This section explains how to install the interface card.
Caution!
There is electricity present and therefore a risk of an electric
shock. Switch off the printer and remove the plug from the
power socket.
Warning!
Static charges can damage the interface. Leave the interface
card in its protective packing until the instructions describe
when to install it.
1. Switch off the printer and remove the parallel interface cable.
