Chapter 11: IBM - Graphics
11-13
bit number of the graphic byte assigned printer pins
7 (MSB) 1
6 or 5 2
43
34
2 or 1 5
0 (LSB) 6
7 (MSB) 7
6 or 5 8
49
310
2 or 1 11
0 (LSB) 12
7 (MSB) 13
6 or 5 14
415
316
2 or 1 17
0 (LSB) 18
7 (MSB) 19
6 or 5 20
421
322
2 or 1 23
0 (LSB) 24
In order to guarantee the grouping of graphic lines described abo-
ve, the following conditions must be fulfilled:
• The line spacing must be 8/240 inch.
• The command sequences with ESC Z commands must be sepa-
rated in each case by a carriage return (CR) and a line feed (LF).
• The length of the graphic lines may not go beyond the right mar-
gin of the page.
• The time pause between the two commands may be no longer
than one second.
