D-4
Appendix D: Interface Data
Daten
Parallele Daten
(Datenbit 1 bis 8)
BUSY
0 µs (min.)
ACKNOWLEDGE
STROBE
250 ns (min.)
2,4 µs
2,4 µs
To test the interface connection turn the computer and the printer
on (POWER ON). Write the following test programme:
10 LPRINT “Everything’s okay”
20 LPRINT “1/6 inch line spacing”
30 LPRINT CHR$ (12);: REM Line Feed
Type RUN and press the Return key. You will get the following
print-out.
Everything’s okay
1/6 inch line spacing
If everything is working properly you can start printing.
Testing the
Interface
Parallel Data
(Data Bit 1-8)
Timing
Data
