Chapter 3: Paper handling
3-9
2. Press downwards on the
back of the paper support.
This will release it from its
catch. Remove it from the
printer and place it to one
side.
Warning!
Direct pressure on the platen can cause damage to the print
head and pins.
Make sure the paper guide is correctly adjusted.
3. Release the catch lever of the
left sprocket drive, adjust
this to the required position
and fasten the sprocket drive
again.
