Page: 101
Service Guide ML390/391
Chapter 4 Failure & Repair Analysis
4.8.05 Line Feed Motor
Name Signal Name Connection
(Refer to
Interconnect
Diagram)
Coil Resistance
Line Feed Motor Phase 1 2
1
Phase 2 3
4
Copyright 1997, Okidata, Division of OKI America, Inc. All rights reserved. See the OKIDATA Business
