Page: 25
Service Guide ML520/521
Chapter 2 Principles of Operation
Electrically Erasable Programmable Read Only Memory (EEPROM)
(Location 03C: 93CS46)
The EEPROM is a CMOS serial I/O type memory (EEPROM). It is capable of electrically erasing and
writing 1,024 bits.
The EEPROM contains the menu data and the head drive time correction data.
