XYAA6338 Service Manual 4-3
See also the following sections:
•
Selectable Parameters
•
Selecting the Parameters
4.2.2 Selectable Parameters
The parameters that can be selected via Setup are
grouped as indicated in the following diagram, which is
similar to the one prined by the machine:
EMULATION
EMULATION: EPSON TM-U590
I/O
I/O: SERIAL - EXIT
SERIAL: BIT
BIT: 8 - 7
SERIAL: BAUD
BAUD: 9600 - 4800 -2400 -1200
SERIAL: STOP
STOP: 1 - 2
SERIAL: PARITY
PARITY: NONE - ODD - EVEN
SERIAL: HANDSHAKE
HANDSHAKE: DTR - XON/XOFF
I/O: EXIT
USER
USER: NATION - CPI - OPTION - EXIT
USER: NATION
NATION: CP437 - CP850 - CP852 - CP858 -
CP860 - CP863 - CP864 - CP865 -
CP866
USER: CPI
CPI: 12.5 - 16.6
USER: OPTION:
CHEQUE PRINT: FRONT - REAR
AUTO LF: NO - YES
RECEIVE BUFFER: 45 - 2048
BUSY OFFLINE: NO - YES
HW RES PIN6: YES - NO
HW RES PIN25: YES - NO
TOP LOW: 1 -2 - 4 - 6 - FULL
FEEDER: FRONT - TOP
SAVE
SAVE: PRINT - SAVE - DEFAULT - RESTART
