DMTA-10043-01EN, Rev. C, July 2016
Initial Setup
33
This means that the gage requires the following transducer zero compensation
step.
3. Wipe any couplant from the tip of the transducer.
4. Press [2
nd
F], [CAL ZERO] (Do‑ZERO).
The gage displays a zero value and then displays the measurement screen (see
Figure 4-2 on page 33).
Figure 4‑2 The Zero screen
5. You are now ready to make measurements. The current units are indicated on the
right of the display. Alternate between millimeters (MM) and inches (IN) by
pressing [2
nd
F], [] (SETUP), then pressing [] to highlight the current display
units and using [, ] to select imperial (inches) or metric (millimeters) units.
6. Press the [MEAS] key.
The initial setup is not a substitute for doing a standard calibration (see “Standard
Calibration Measurement” on page 35).
