Highlighted parameters indicate that the specific self-test failed based on the expected
values.
To view the Diagnostic 2 screen, which shows information about your 27MG instrument
1. Press [2
nd
F] [] (SETUP) to display the setup tabs.
2. Use the [, ] keys to highlight the DIAG2 tab.
The results provided in Table 9 on page 72 are displayed.
Table 8 DIAG1 results
GAIN Internal Calibration
BLK, DET,
SMP
Internal Blank, Detector and
Sampler Test
THRESH
CAL
(RCVR1)
Threshold Calibration Test
Receiver 1
THRESH
CAL
(RCVR2)
Threshold Calibration Test
Receiver 2
Table 9 DIAG2 results
SW REV Reports software version (1.00/1.00G)
BATTERY Indicates current battery voltage
PROBE Indicates current attached probe
PR TX Indicates the time of flight for the
transmit delay line
PR RX Indicates the time of flight for the
receiver delay line
