OMA 511 - Hydraulic Oil Diagram; Oil; Pump; Electric Motor

MOTOREELETTRICO:
Trifase Monofase
Potenzadelmotore
elettrico
2,2KW 2,2KW
Tensione 230-400Vtrif.+/-5% 230Vmono+/-5%
Frequenza 50Hz 50Hz
Assorbimento 230V:10.7A
400V:6.2A
15.9A
N°poli 4
Velocità 1400Giri/1’ 1380Giri/1’
Formacostruttiva B14
Classediisolamento F IP54
Tipo C90 M90LB4
Ilcollegamentodelmotoredeveessereeseguitoriferendosiagli
schemielettriciallegati.
Ilsensodirotazionedelmotoreèsinistro(antiorario)comeindica
-
tonellatarghettaapplicataalmotorestesso.
POMPA
Tipo ...........................................................18
Modello......................................................10A5X348N
Cilindrata ...................................................5cm3/g
Taraturavalvoladimassima .....................160bar
OLIO
Ilserbatoiodell’oliocontieneolioidraulicomineralesecondolanor-
mativaISO/DIN6743/4congradodicontaminazionenonsuperiore
allaclasse18/15secondolanormativaISO4406esempioolioIP
HYDRUSOIL32;SHELLTELLUSOILT32oequivalenti.
SCHEMAOLEODINAMICO
Rif. Descrizione
1
Cilindro
2
Valvolareg.flusso
3
Elettrovalvoladiscarico
4
Valvoladinonritorno
5
Valvoladimassima
6
Pompa
7
Motore
8
Filtro
9
Valvoladiblocco
10
Serbatoio
Fig.10 Schemaoleodinamico
ELECTRICMOTOR
Three-phase Singlephase
Electricmotorpower
rating
2,2KW 2,2KW
Voltage 230-400V3ph.+/-5% 230V1ph.+/-5%
Frequency 50Hz 50Hz
Absorption 230V:10.7A
400V:6.2A
15.9A
No.ofpoles 4
Speed 1400RPM 1380RPM
Constructionsize B14
Insulationclass F IP54
Type C90 M90LB4
Themotormustbeconnectedwithreferencetotheattachedwiring
diagrams.
Themotorrotatestotheleft(counterclockwise)asindicatedonthe
dataplateattachedtothemotor.
PUMP
Type ..........................................................18
Model.........................................................10A5X348N
Size ...........................................................5cm3/g
Reliefvalveset-up.....................................160bar
OIL
Theoilreservoircontainshydraulicmineraloilinaccordancewith
ISO/DIN6743/4withalevelofcontaminationthatdoesnotexceed
class18/15accordingtoISO4406,forexampleIPHYDRUSOIL
32;SHELLTELLUSOILT32orequivalent.
HYDRAULICOILDIAGRAM
Ref. Description
1
Cylinder
2
Flowcontrolvalve
3
Drainelectro-valve
4
Checkvalve
5
Maximumvalve
6
Pump
7
Motor
8
Filter
9
Lockvalve
10
Reservoir
Fig.10Hydraulicoildiagram
9
1
2
3
4
9
5
7
6
10
8
