TIPIDIVEICOLISOLLEVABILIEINGOMBRI
Ilsollevatoresiadattapraticamenteatuttiiveicolidipesononsu
-
periorea3000Kgelecuidimensioninoneccedanoquelleriporta
-
tediseguito.
DIMENSIONIMASSIMEDEIVEICOLIDASOLLEVARE
Lalarghezzanondeveeccederei2200mm.
Ilpassotragliassinondeveeccederei3000mm.
L’altezzaminimadaterrapuòinterferireconlestrutturedel
sollevatore.Fareattenzionesoprattuttoalleautovetturesporti
-
ve.
Eventualicarrozzatispecialipossonoesseresollevatitenendo
peròcontodellaportatadelsollevatore.
Anchelazonadirischioperlepersonedovràessereadeguata
alledimensionispecialidelveicolo.
Glischemiseguentiriportanoicriteriperdefinireilimitidiimpiego
delsollevatore.
Fig.13 Misureminimeemassime
PERINGOMBRIMAGGIORIVERIFICAREILCARICOMASSIMO
ELOSBILANCIAMENTODELCARICO.
PESIMASSIMIDEIVEICOLIDASOLLEVARE
Fig.14 Distribuzionedeipesi
VEHICLEWEIGHTANDSIZE
Liftrackcanbeadaptedtovirtuallyallvehiclesnoheavierthan
3000kg,thedimensionsofwhichdonotexceedthefollowing.
MAXIMUMDIMENSIONSOFVEHICLESTOBELIFTED
Max.width:2200mm.
Max.wheelbase:3000mm.
Theunderbodyofcarswithlowgroundclearancemayinterfe
-
rewiththestructureofthelift.Payparticularattentioninthe
caseoflowbodysportscars.
Alwayskeepthecapacityoftheliftinmindinthecaseofvehicles
withparticularcharacteristics.
Thedangerzonewillbedeterminedbythedimensionsofthe
vehicle.
Thediagramsbelowincludethecriteriafordefiningthelimitsof
useofthecarrack.
Fig.13 Minimumandmaximumdimensions
CHECKMAXIMUMLOADCAPACITYANDLOADDISTRIBU
-
TIONINTHECASEOFLARGERVEHICLES.
MAXIMUMWEIGHTOFTHEVEHICLETOBELIFT
Fig.14 Weightdistribution
12
I
MAX.3000Kg.!
1800
1200 1200
1800
Min.(mm) Max.(mm)
A
- 2200
B
- 3000
C
150 -
A
C
